2715 Insulation PVC Fiberglass Sleeving (2715)
- Payment Type:
- L/C, T/T, Western Union
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | China |
|---|---|
| Payment Type: | L/C, T/T, Western Union |
Product Description
Product Description
Product Description
2715 insulation PVC fiberglass sleeving
Heat-resistance: A class 105C
Breakdown Voltage: 2.5KV 4KV
Material: Alkali-Free fiberglass braided sleeving
Coating: Polyvinyl chloride resin(PVC resin)
Property: Excellent electrical, chemical and oil resistance properties.
High heat stability and flexibility.
Used for the wiring insulation and mechanical protection for motors, electrical appliances, electrical instruments, wireless sets and domestic electrical appliances
Size I. D.: 1-30mm
Length: In one meter or in coils. 50m 100m for one coils, also can be accroding to your request
Pacage: Carton
Heat-resistance: A class 105C
Breakdown Voltage: 2.5KV 4KV
Material: Alkali-Free fiberglass braided sleeving
Coating: Polyvinyl chloride resin(PVC resin)
Property: Excellent electrical, chemical and oil resistance properties.
High heat stability and flexibility.
Used for the wiring insulation and mechanical protection for motors, electrical appliances, electrical instruments, wireless sets and domestic electrical appliances
Size I. D.: 1-30mm
Length: In one meter or in coils. 50m 100m for one coils, also can be accroding to your request
Pacage: Carton
| Nominal size | Tolerance | Wall thickness |
| 0.5-0.8 | ± 0.10 | 0.25-0.40 |
| 1.0-1.5 | ± 0.15 | 0.20-0.50 |
| 2.0-2.5 | ± 0.20 | 0.35-0.60 |
| 3.0-6.0 | ± 0.25 | 0.35-0.70 |
| 7.0-10.0 | ± 0.50 | 0.55-0.90 |
| 12.0-18.0 | ± 0.50 | 0.70-1.20 |
| 20.0-30.0 | ± 0.50 | 0.90-1.30 |
| Test condition Axes 25mm, electrode type | type | ||
| 2715-1 | 2715-2 | 2715-3 | |
| Center value | ≥ 7.0 | ≥ 4.0 | ≥ 2.5 |
| Lowest individual value | ≥ 5.0 | ≥ 2.5 | ≥ 1.5 |
