Electrical insulation Nomex/polyimide film/Nomex NKN

Specifications high quality and competitive price NKN



No.	Properties	Unit	Values
1	Nominal Thickness	mm	0.15	0.17	0.20	0.25	0.30	0.33
2	Thickness Tolerance	mm	±0.02		±0.03	±0.04		±0.05
3	breakdown voltage ( No Bending) ≥	kv	8		9		10
4	Bond Strength At Room Temp.	—	No delamination
5	Bond Strength At (200±2)℃, 10 min	—	No delamination, No blister, No adhesive flow

  6650 NKN----Nomex paper/kapton/Nomex paper flexible composite material is made of two layers of Du Pont Nomex paper with one layer of polyimide film. Features and applications of NKN:                                             -Temp.class H(180 ºC)                                                       -Excellent dielectric and mechanical property, even better properties of dielectric and mechanical under high temperature or after humidity.                             -As slot, interturn and liner insulation for H-grade motors and electric appliances.  Availablity of NKN:                                                                 -Form: roll, sheet, strip.     For more information please contact sales of YAAN Insulation Ms. Chrystal Zhai.
