Insulation materials-Prepreg DMD

Specifications Insulation materials-Prepreg DMD

Good quality and competitive price

Approved by UL and ROHS

Insulation materials-prepreg DMD Insulation materials-Prepreg DMDis features and Applications:
- Prepreg DMD is Class F insulation (155°C)
- Prepreg DMD can be used as Interlayer insulation of copper foil (aluminium foil)-wrapped low voltage coils in dry-type transformers, slot insulation and interphase insulation in F class motor and electrical appliances

Insulation materials-Prepreg DMD's availability:
-Thickness: 0.16mm-0.25mm
- Form: rolls(width 1000mm), sheets, strips(width >5mm)
- Colour: red
Technical data:

No.	Properties	Unit	Values
1	Nominal Thickness	mm	0.16	0.18	0.20	0.23		0.25
2	Thickness Tolerance	mm	±0.003		±0.035
3	Tensile Strength MD, No Bending	N/10mm	≥70		≥80		≥100
4	Resin Content	%	35±5		30±5
5	Volatile Content	%	≤1.5
6	Soluble Resin Content	%	≥85
7	Dielectric Strength	Kv/mm	≥40
8	Tensile Shear Strength	Mpa	≥3.0

  For more information please contact sales of YAAN Insulation Ms. Belinda Chen
