insulation cloth 2432 insulation Alkyd varnished glass cloth tape

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Henan, China (Mainland)

Product Description

2432 insulation Alkyd varnished glass cloth tape Main raw materials: E-glass fiber cloth , Alkyd resin 2432 insulation Alkyd varnished glass cloth tape's Features: Alkyd varnished glass cloth with excellent dielectric , mechanical property and heat resistance, good oil, fungus and humidity-heat resistance Temp. Class: 130 degree Celsius. 2432 insulation Alkyd varnished glass cloth tape's Application: It is used as coil insulation for oil-immersed transformers and oil circuit breakers. 2432 insulation Alkyd varnished glass cloth tape's technical data:

Properties

Units

Values

Nominal thickness

0.10

0.12

0.15

0.18

0.20

Oil resistance

Not lower than breakdown voltage at 23±2°C

Humidity-heat resistance

Varnished film shall not be peeled off

Flexibility resistance

Not break the medium value of breakdown voltage at bended place shall not be less 50% than that at unbended place

Tensile strength

Length

N/10mm

≥65

≥85

≥105

≥111

≥118

Cross

≥45

≥52

≥65

≥78

≥85

45°

≥40

≥60

≥65

≥78

≥70

On lapping place cut on bias

Before impregnation

≥20

≥25

≥30

After impregnation

≥20

≥30

Breakdown voltage

Under 23±2°C

Medium

≥5.0

≥6.0

≥7.0

≥8.0

≥9.0

Min

≥4.0

≥4.5

≥6.0

≥6.5

≥7.0

Under 130±2°C

Medium

≥2.5

≥3.0

≥3.5

≥4.0

≥4.5

The quality warranty period

Six months(under 25°C)
